Technical Data:
- Max Cutting Length : 2800mm
- Max Cutting Thickness : 100mm
- Positioning Method : Automatic
- Cutting Accuracy : ±0.15mm
- Positioning Accuracy : ±0.02mm
- Secondary Saw Speed : 6100r/min
- Main Saw Blade Diameter : 400mm
- Small Saw Blade Diameter : 180mm
- Main Shaft Diameter : 60mm
- Small Shaft Diameter : 30mm
- Main Saw Speed : 5100r/min
- Feeding Speed : 0 ~ 60m/min
- Saw Car Servo Motor Power : 1.5kw
- Cutting Speed : 0 ~ 80M/min
- Manipulator Servo Motor : 1.5kw
- Return Speed : 0 ~ 120m/min
- Air Pressure : 0.6 ~ 0.7mpa
- Net Weight : 5200kg
- Total Power : 22kw
- Overall Size (L x w x H) : 5100 x 5600mm
