Description

ZapZoom Plus Wallbox EV Charger • IEC 62196-2 Type 2

ZapZoom Plus 22kW AC EV Charger

Buy one smart charger for single phase use today and 22kW three phase charging tomorrow.

ZapZoom Plus 22kW AC Charger is a smart Type 2 wallbox EV charger for EV owners who want a future-ready charging solution for home, office or commercial premises.

The same 22kW charger can be installed and configured for single phase charging when your current house supply is single phase. Later, when your home is upgraded to three phase supply, the charger can be reconfigured and used for up to 22kW three phase AC charging, subject to electrical installation and vehicle onboard charger capability.

This helps avoid buying one charger now and another charger later when your electrical supply is upgraded.

22kW 3 Phase Ready Single Phase Usable Future Upgrade Friendly IEC 62196-2 Type 2 OCPP 1.6J Bluetooth / Wi-Fi / Ethernet / 4G RFID Card Dynamic Load Balance 3 Years Warranty

Request Quotation Installation Enquiry

Single Phase Now. Three Phase Later. Same Charger.

Many homes in Malaysia are currently supplied with single phase electricity. For daily overnight EV charging, this may already be enough for many users. However, as EV battery sizes grow and home electrical demand increases, some owners may later upgrade their home supply to three phase.

The ZapZoom Plus 22kW charger is useful because it is not limited to only today’s supply arrangement. It can be installed for single phase use first, then later reconfigured for three phase 22kW charging after your house supply is upgraded.

This is the main advantage: buy the 22kW charger once, use it on single phase today, and continue using the same charger when your home is upgraded to three phase.

Final charging power will depend on your TNB supply, wiring design, protection devices, charger settings, and your EV’s onboard AC charging limit. Proper site assessment and commissioning are required.

1Φ

Use with Single Phase Supply

For existing single phase homes, the charger can be connected and configured to operate at suitable single phase charging power based on site capacity.

3Φ

Upgrade to Three Phase Later

When your home supply is upgraded to three phase, the same charger can be rewired and reconfigured for higher three phase AC charging.

22kW

Up to 22kW Charging

With three phase 380Vac supply, the ZZ220W3-T2 model supports up to 22kW charging with adjustable current from 8A to 32A.

Why Choose ZapZoom Plus?

ZapZoom Plus is designed for EV owners and premises that need more than a basic charger. It combines high-power AC charging, smart communication, RFID access, app control, LCD display and third-party platform integration support.

The 22kW version is especially suitable for buyers who want a charger that is ready for the future, instead of buying a lower-capacity charger now and replacing it after an electrical upgrade.

ZapZoom Plus is a smart connected EV charging point with OCPP, RFID, app control, LCD display, dynamic load balance support and 3 years warranty.

Actual charging speed depends on vehicle onboard AC charger, site electrical supply, charger setting, cabling, protection and installation design.

ZapZoom Plus Model Range

ZZ070W3-T2

7kW single phase model for 230Vac supply with adjustable 8A to 32A charging current. Suitable for single phase home and small premise charging.

ZZ110W3-T2

11kW three phase model for 380Vac supply with adjustable 8A to 16A charging current. Suitable for moderate three phase AC charging.

ZZ220W3-T2

22kW three phase model for 380Vac supply with adjustable 8A to 32A charging current. Also suitable for future upgrade planning where single phase is used first and three phase is planned later.

Compatible with Type 2 EVs

ZapZoom Plus uses the IEC 62196-2 Type 2 charging plug, widely used by many electric vehicles in Malaysia and globally.

IEC 62196-2 Type 2

Compatible with EVs that support Type 2 AC charging, including many models from BYD, Tesla, BMW, Mercedes-Benz, Volvo, Hyundai, ORA and others.

Level 2 AC Charging

Designed for AC charging at homes, offices, commercial buildings, private parking bays and semi-public charging points.

Generic EV Charger

A practical charger option for users who may change EV brand in the future but want to retain the same Type 2 wallbox charger.

Smart Charging Features

APP

App Control

Start and stop charging, view historical charging records, select charging schedule and set charging current.

RFID

RFID Card Control

RFID access control helps prevent unwanted use and is suitable for shared or controlled charging areas.

OCPP

OCPP 1.6J

Supports OCPP 1.6J communication for third-party platform integration and charger management systems.

COM

Multiple Communication Options

Supports Bluetooth, Wi-Fi, Ethernet, 4G and RFID Card to meet different site and user requirements.

DLB

Dynamic Load Balance

Supports dynamic load balance and external smart meter integration to help manage available electrical capacity.

LCD

LCD Display

LED indicator and LCD display allow easy checking of charging status and charger information.

Built-In Safety Protection

ZapZoom Plus includes multiple electrical protection features to support safer EV charging operation.

Type B Leakage Protection

Leakage protection Type B with AC 30mA + DC 6mA residual current protection.

Residual Current and Ground Protection

Includes residual current protection and ground protection to support safe charger operation.

Over Current Protection

Over-current protection helps reduce risk during abnormal charging current conditions.

Voltage and Frequency Protection

Includes over / under voltage protection and over / under frequency protection.

Surge and Temperature Protection

Includes surge protection and over-temperature protection for safer daily charging.

Optional PEN-Fault Protection

PEN-fault protection is available as an optional safety feature where required.

3 Years Warranty for Better Peace of Mind

ZapZoom Plus is positioned as a long-term EV charging investment. The charger comes with 3 years warranty, giving buyers better confidence when selecting a future-ready 22kW AC charger.

When combined with proper installation, correct protection selection, trip testing and commissioning, the warranty support makes ZapZoom Plus a stronger option for home and commercial EV charging projects.

A future-ready charger should not only be powerful. It should also be supported, properly installed and commissioned.

Build Quality and Outdoor Readiness

IP65 Protection

IP65 rated enclosure for practical indoor, outdoor and semi-outdoor installation environments.

Flame-Retardant Housing

Thermoplastic shell with flame-retardant grade UL94V-0.

Pure Copper Silver-Plated Pins

Charging plug pins use pure copper with silver plating for reliable electrical contact.

High-Quality Cable

Halogen-free charging cable with pure copper core and TPU cable jacket.

4.5m Cable Length

Standard cable length is 4.5 meters, with customised cable length option where available.

Mechanical Life

Designed for more than 10,000 mechanical plug-in cycles.

Installation, Testing and Commissioning

ZapZoom Plus should be installed with proper cable sizing, protection, isolation, earthing verification, trip testing and commissioning.

Single Phase Installation First

For homes with existing single phase supply, the charger can be installed and configured for suitable single phase charging.

Three Phase Upgrade Later

When the house supply is upgraded to three phase, the same charger can be reconnected and commissioned for three phase charging.

Trip Test and Verification

Testing and commissioning can include AC / DC trip verification using Fluke 1664FC Multifunction Tester where applicable.

Charging Time Guide

Charging time varies depending on battery size, charger setting, vehicle onboard charger, environmental conditions and site electrical supply. The guide below provides estimated full-charge times shown in the brochure.

Vehicle Example	Usable Battery	ZZ220W3-T2 22kW / 32A 3 Phase	ZZ110W3-T2 11kW / 16A 3 Phase	ZZ070W3-T2 7kW / 32A 1 Phase
Tesla Model 3 Standard Plus	50.0kWh	2.27 hours	4.55 hours	7.14 hours
Tesla Model Y Performance	72.5kWh	3.29 hours	6.59 hours	10.36 hours
Ford Mustang Mach-E	70.0kWh	3.18 hours	6.36 hours	10.0 hours
Volkswagen ID.4	77.0kWh	3.50 hours	7.00 hours	11.0 hours
Nissan Leaf e+	56.0kWh	2.55 hours	5.10 hours	8.00 hours
Audi e-tron / Sportback	86.5kWh	3.93 hours	7.86 hours	12.36 hours
Hyundai Kona Electric	64.0kWh	2.90 hours	5.80 hours	9.14 hours
Porsche Taycan	83.7kWh	3.80 hours	7.60 hours	11.96 hours
BMW i3 120 Ah	37.9kWh	1.72 hours	3.44 hours	5.40 hours

Technical Summary

Parameter	ZZ070W3-T2	ZZ110W3-T2	ZZ220W3-T2
Charging Power	7kW	11kW	22kW
Power Supply	1 Phase	3 Phase	3 Phase
Input Voltage	230Vac ±15%	380Vac ±15%	380Vac ±15%
Rated Current	8–32A	8–16A	8–32A
Charging Type	Level 2 AC charging
Charging Plug	IEC 62196-2 Type 2
Power Plug / Connection	CEE Blue 3-Pin / Hardwire 3-Core	CEE Red 5-Pin / Hardwire 5-Core	CEE Red 5-Pin / Hardwire 5-Core
Charging Cable	3 × 6.0mm² + 0.5mm²	5 × 2.5mm² + 0.5mm²	5 × 6.0mm² + 0.5mm²
User Interface	LED indicator and LCD display
Communication	OCPP 1.6J, Bluetooth, Wi-Fi, Ethernet, 4G and RFID Card
Smart Support	Dynamic load balance and OCPP communication with third-party platform
Working Temperature	-25°C to +55°C; -35°C optional
Humidity	5% to 95% non-condensing
IP Rating	IP65
Work Altitude	<2000m
Control Box Size	L285 × W245 × H88mm
Cable Length	4.5 meters / customised
Net Weight	4.05kg	4.22kg	5.35kg
Warranty	3 years warranty, subject to warranty terms and correct installation conditions

Product Summary

ZapZoom Plus 22kW AC EV Charger is a smart Type 2 wallbox charger for buyers who want a charger that can be used on single phase supply today and upgraded for 22kW three phase charging later.

With OCPP 1.6J, Bluetooth, Wi-Fi, Ethernet, 4G, RFID Card, app control, LCD display, dynamic load balance, IP65 protection, Type B leakage protection and 3 years warranty, ZapZoom Plus is suitable for homes, offices, commercial premises and shared charging applications.

ZapZoom Plus 22kW — Buy Once. Use on Single Phase. Upgrade to Three Phase Later.

Contact us for charger selection, single phase / three phase assessment, installation quotation and testing & commissioning support.
