Parameter	Description
Part Number	SKD75GAL123D16L2
Type	Power MOSFET
Package	DPAK (TO-252)
VDS (Max Drain-Source Voltage)	75V
RDS(on) (Typical On-Resistance)	12.3 mΩ @ VGS = 10V, ID = 40A
ID (Continuous Drain Current)	40A @ TC = 25°C
PD (Power Dissipation)	20W @ TC = 25°C
fT (Transition Frequency)	2.8 MHz
Qg (Total Gate Charge)	55 nC
Input Capacitance (Ciss)	1950 pF
Output Capacitance (Coss)	360 pF
Reverse Transfer Capacitance (Crss)	250 pF
Operating Temperature Range	-55°C to +150°C
Storage Temperature Range	-65°C to +175°C

Mounting: Ensure the device is mounted on a suitable heatsink to maintain operating temperatures within specified limits.
Handling: Handle with care to avoid damage to the leads and package. Follow ESD precautions to prevent damage from static electricity.
Soldering: Use a temperature-controlled soldering station. Do not exceed 260°C for more than 10 seconds during soldering operations.
Testing: Before applying voltage, ensure all connections are correct and secure. Test in a controlled environment to avoid damage.
Application: Suitable for high-frequency switching applications, motor control, and power supplies. Ensure the drain current does not exceed the rated continuous drain current under any operating conditions.
