Palletizing Robot IRB 460

详情

High-Speed Palletizing Robot for Fast and Efficient Handling



The IRB 460 is a 4-axis palletizing robot built for high-speed handling in end-of-line and bag palletizing operations. With a reach of 2.4 meters and 110 kg payload, this single-variant robot offers fast and precise motion in a compact form factor, capable of achieving up to 2,190 cycles per hour.

Its integrated design includes IP67 protection, internal cabling options, and support for process-specific configurations such as FlexGripper claws. Motion control is powered by the OmniCore platform, which also enables safety functions and supports application flexibility through RobotStudio and Palletizing PowerPac.

• Compact 4-axis design with 110 kg payload and 2.4 m reach
• Capable of up to 2,190 cycles/hour with a 60 kg load
• Position repeatability of 0.2 mm; path repeatability of 0.11 mm
• Small footprint allows closer pallet placement and higher cell density
• IP67-rated for demanding industrial environments
• Compatible with multiple gripper types and process cables
• Powered by OmniCore controller family for advanced motion and safety

Max Payload = 110 kg
Max Reach = 2.4 m
Max Position Repeatability = 0.2 mm
Recommended Applications = Palletizing / Depalletizing, Material Handling
