AMPERES PD1240

• 24 zone console with soft touch buttons

• Built-in chime for clear alerts

• Adjustable mic and chime volume

• Priority override for seamless control

• Compatible with all decoders, Matrix controllers, and iPX5151 / iPX5155


  PD1240
  Power requirements
  Operating voltage	24V DC via EX2800 with local power adaptor
  Power consumption (24V DC)	1.2W
  Input, output and controls
  Zone selection	24 zone keys, Group, All Call
  Switching selection	Sensor touch keypad
  Microphone	Gooseneck condenser capsule ; unidirectional
  Output impedance	600 Ohm
  Output level	1.2V Balanced line output (+4 dBU)
  Output controls	Chime and microphone volume
  Data connections	RS485 ; 19.2 Kbps
  Cabling to decoder	2 pair screen: 22 AWG / Cat5e
  Recommended operating distance	500m max (18 AWG Cable)
  Compatible interface device	MxP2288, TD6240, TD6400
  Chime	4 tone up and 4 tone down
  Indicators	Zone, power, audio, data, gooseneck ring LED
  Displays	NIL
  Frequency response	100 - 12 kHz @ 1 kHz +/- 3 dB
  S/N ratio	> 65 dB at 1 kHz
  Gooseneck microphone length	370mm
  Case
  Dimensions (W x H x D)	230 x 192 x 65 mm (Excluding microphone)
  Weight	0.75kg

•
