Dual-mode siren tone activation
Built-in siren tone generator
Large FIRE alert indicator
External voice message activation capability
Output level controls for siren, message, and paging microphone
Dry contact output when paging microphone is activated
| EP1200 | |
| Power requirements | |
| Operating voltage | 24V DC |
| Power consumption | 3.5W |
| Input, output and controls | |
| Mic sensitivity | -72 dB Omni directional |
| Impedance | 600 Ohm |
| Frequency response | 300 ~ 8 kHz |
| Siren frequency | Continuous at 8 kHz |
| Siren duration | Continuous when activated |
| Siren activation | Front test switch / remote contact |
| Input channel | Pre-amplifier output, message recorder |
| Output level | Balanced line out +4 dBU max |
| Priority sequence | Paging mic -siren -message -pre amp in |
| Indicators | Front FIRE with back light illumination |
| Case | |
| Dimensions (W x H x D) | 482 x 88 x180 mm |
| Weight | 2.80kg |
| Dimensions (W x H x D) | 160 x 50 x 120 mm (Excluding microphone) |
| Weight | 0.38kg |
