MT100185 series provides a 100mm through-bore for routing of hydraulic or pneumatic lines or
hydraulic or pneumatic rotating shaft installation, and a compact 185mm outside diameter,features
long life, fiber brush contact technology for ultimate performance in manychallenging applications.
MT100185 series are standard, off-the-shelf products, Color-coded lead wires are used onboth the
stator and rotor for simplified electrical connections.It can transmit signal(2A), 10A, multiple 10A
current when 360° degree free rotating.
Model :
.png)
.png)
.png)
