Highest precision from direct saw head mount
-
Compact light weight, suitable also for one-handed transport
-
Robust die-cast aluminium design for the highest demands
-
Easy transport thanks to ergonomically-designed handles and saw head lock
-
Effective dust extraction via integrated dust scoop
-
Fast and precise setting of common angles using stop points
-
High sliding rear fence profiles for safe sawing
-
Material clamp for secure fixing of the work piece from the top or front
-
Integrated, pull to table width extensions made from die-cast aluminium
-
All scales and operating elements are visiable from the working position and can be operated intuitively
-
Easy saw blade change by means of spindle lock: No dismantling of the pendulum protective cover required.
|
Model |
KS 305 Plus |
|
Dimension |
725 x 758 x 637 mm |
|
Bearing surface |
225 x 1080 mm |
|
Maximum cutting width 90°/ 45° |
200 mm/ 140 mm |
|
Maximum cutting depth at 90°/ 45° |
100 mm/ 45 mm |
|
Maximum cross-section of the workpiece (straight cut 90°/90°) |
200 x 77 mm |
|
Maximum cross-section of the workpiexe (double mitre 45°/ 45°) |
140 x 35 mm |
|
No-load speed |
4100 /min |
|
Speed at rated load |
3015/ min |
|
Cutting speed |
48 m/s |
|
Saw blade |
305 x 30 mm |
|
Turntble setting left/ right |
47° / 47° |
|
Rated input power |
2 kW |
|
Weight |
19 kg |
