Description
BUY HI7133CPL https://www.utsource.net/itm/p/451998.html
| Parameter |
Description |
Value |
Unit |
| Input Voltage |
Operating voltage range |
4.5 to 5.5 |
V |
| Output Current |
Maximum output current |
100 |
mA |
| Quiescent Current |
Current consumption in active state |
2 |
mA |
| Shutdown Current |
Current consumption in shutdown mode |
0.1 |
μA |
| Operating Temperature |
Temperature range for operation |
-40 to 85 |
°C |
| Package Type |
Type of package |
SOT-23 |
- |
| Storage Temperature |
Temperature range for storage |
-65 to 150 |
°C |
Instructions:
- Power Supply Connection: Connect the input voltage between 4.5V and 5.5V to the VIN pin. Ensure that the power supply is stable and within the specified range to avoid damage to the device.
- Output Connection: Connect your load to the VOUT pin. The maximum current that can be drawn from this pin is 100mA.
- Ground Connection: Ensure a common ground connection between the power supply, HI7133CPL, and the load.
- Thermal Considerations: Operate the device within the specified temperature range (-40°C to 85°C). For extended periods of high current draw, consider heat dissipation methods.
- Shutdown Mode: To enter shutdown mode, pull the SHDN pin low. This reduces the current consumption to approximately 0.1μA.
- Storage Handling: When storing the device, ensure temperatures remain between -65°C and 150°C to prevent damage.
- Package Handling: Handle the SOT-23 package with care to avoid physical damage. Follow standard ESD (Electrostatic Discharge) precautions during handling and installation.
