Description

Parameter	Description	Value	Unit
Part Number	Device Identifier	D3728DZ	-
Type	Component Type	Diode	-
Package	Package Type	DO-214AA (SMA)	-
Polarity	Diode Polarity	Uni-directional	-
Maximum Repetitive Peak Reverse Voltage (VRRM)	Maximum Reverse Voltage	600	V
Maximum Average Rectified Forward Current (IF(AV))	Continuous Forward Current	450mA	mA
Peak Forward Surge Current (IFSM)	Non-repetitive Peak Forward Current	3.9A	A
Junction Operating Temperature Range (TJ)	Operating Temperature Range	-55 to +175	°C
Storage Temperature Range (TSTG)	Storage Temperature Range	-55 to +150	°C
Reverse Recovery Time (trr)	Reverse Recovery Time	35	ns

Handling and Storage:
- Store the device in a dry, cool place within the temperature range specified.
- Handle with care to avoid damage to the leads or body.
Mounting:
- Ensure proper orientation during mounting to respect the polarity of the diode.
- Follow manufacturer guidelines for soldering temperatures and times to prevent thermal damage.
Electrical Connections:
- Connect the anode and cathode terminals correctly according to circuit design.
- Do not exceed the maximum ratings listed for reliable operation.
Thermal Management:
- Consider heat dissipation requirements based on the application’s power handling needs.
- Use appropriate heatsinks if necessary to maintain junction temperature within limits.
Testing:
- Perform initial testing under controlled conditions to verify correct installation and functionality.
- Regularly inspect connections and components for signs of wear or damage.

(For reference only)
