Parameter	Symbol	Conditions	Min	Typ	Max	Unit
Supply Voltage	VDD	Operating	2.7	-	5.5	V
Operating Temperature	Toper	Storage	-40	-	85	°C
Input Voltage Range	VIN	Differential Mode	-0.3	-	VDD+0.3	V
Output Current	IOUT	Continuous	-	100	250	mA
Quiescent Current	IQ	No Load	-	1.2	-	mA
PSRR (Power Supply Rejection Ratio)	PSRR	@ 1kHz	-	60	-	dB
CMRR (Common Mode Rejection Ratio)	CMRR	@ 1kHz	-	80	-	dB

Supply Voltage Connection:
- Ensure the supply voltage (VDD) is within the operating range of 2.7V to 5.5V.
Operating Temperature:
- The device can operate between -40°C and 85°C. Avoid exceeding these limits to prevent damage or unreliable operation.
Input Voltage Handling:
- The input voltage should remain within -0.3V to VDD + 0.3V to avoid damaging the device.
Output Current Management:
- The device can provide a continuous output current up to 250mA. For optimal performance, limit the load to ensure the output current does not exceed 100mA continuously.
Quiescent Current Consideration:
- The quiescent current is typically 1.2mA when no load is applied. This value helps in power budget calculations.
Noise Rejection:
- The device provides good noise rejection with a PSRR of 60dB and CMRR of 80dB at 1kHz, enhancing signal integrity in noisy environments.
Installation and Handling:
- Handle the device with care to avoid static damage. Follow standard ESD precautions during installation.
Testing and Troubleshooting:
- Before deploying the device in a live application, thoroughly test it under expected conditions to ensure reliability. Refer to the datasheet for detailed troubleshooting steps if issues arise.
