Item |
Data |
|
|
|
APPROVAL |
|
|
|
|
Test standard |
IEC/EN61984：2009 / UL1059 |
|
|
|
Pitch [mm] |
3.5/3.81 |
|
|
|
Poles |
02~12P/02P~15P |
|
|
|
EN61984 Test data |
VDE certificate NO. 40038730 |
|
|
|
Rated voltage [V] |
250 |
|
|
|
Rated current [A] |
8 |
|
|
|
Rated connection capacity(solid/stranded) [mm2] |
/ |
|
|
|
Surge voltage category/pollution degree/material group |
II/2/III |
|
|
|
Rated impulse voltage [KV] |
2.5 |
|
|
|
Rated torque [N·m] |
/ |
|
|
|
UL1059Test data |
UL File Number E228872 |
|
|
|
Use group |
B |
C |
D |
|
Rated voltage [V] |
300 |
/ |
/ |
|
Rated current [A] |
8 |
/ |
/ |
|
(Rated connection capacity) (solid/stranded) [AWG] |
/ |
|
|
|
Rated torque [Lb. in] |
/ |
|
|
|
General data |
/ |
|
|
|
Screw |
/ |
|
|
|
Inflammability classUL94 |
V-0 |
|
|
|
Ambient temperature [℃] |
-40~+130 |
|
|
|
Relative humidity |
5%-95% |
|
|
|
Inspection standard |
MIL-STD-105E II |
|
|
|
AQL |
0.65 |
|
|
|
Warranty |
12 months |
|
|
|
Material and plating |
/ |
|
|
|
Housing |
LCP |
|
|
|
Contact |
Copper alloy，Sn plated |
|
|
