| ELECTRICAL SPECIFICATION(STC) | |||||
| Maximum Power(Pmax/W) | 620 | 625 | 630 | 635 | 640 |
| Maximum Power Voltage(Vmp/W) | 35.7 | 35.9 | 36.1 | 36.3 | 36.5 |
| Maximum Power Current(Imp/A) | 17.37 | 17.41 | 17.46 | 17.50 | 17.54 |
| Open Circuit Voltage(Voc/V) | 42.9 | 43.1 | 43.30 | 43.5 | 43.7 |
| Short Circut Crrent(Isc/A) | 18.31 | 18.36 | 18.41 | 18.46 | 18.5 |
| Module Efficiency(%) | 21.9 | 22.1 | 22.3 | 22.4 | 22.6 |
| Power Output Tolerance(W) | 0~+5% | ||||
| ELECTRICAL SPECIFICATION(NOCT) | |||||
| Maximum Power(Pmax/W) | 469 | 473 | 476 | 480 | 484 |
| Maximum Power Voltage(Vmp/W) | 33.8 | 33.9 | 34.1 | 34.3 | 34.5 |
| Maximum Power Current(Imp/A) | 13.89 | 13.93 | 13.96 | 13.99 | 14.03 |
| Open Circuit Voltage(Voc/V) | 40.6 | 40.8 | 41.0 | 41.2 | 41.4 |
| Short Circuit Current(Isc/A) | 14.77 | 14.81 | 14.85 | 14.89 | 14.93 |
| MECHANICAL DATA | |
| Number of Cells | 120 pieces(6x20) |
| Dimensions of Module L*W*H(mm) | 2172x1303x35mm |
| Weight(kg) | 35.3kg |
| Front Side Glass | 2.0mm, Anti-reflection coating |
| Back Glass | 2.0mm, HeatStrengthened Glass |
| Frame | Anodized Aluminium |
| J-Box | IP68 Rated |
| Cable | 4.0mm², +300mm |
| Number of diodes | 3 |
| Wind/Snow Load | 2400 Pa/5400pa* |
| Connector | MC4 compatible |
(3)(1).jpg)
.jpg)
