| ELECTRICAL SPECIFICATION(STC) | ||||||
| Maximum Power(Pmax/W) | 605 | 610 | 615 | 620 | 625 | 630 |
| Maximum Power Voltage(Vmp/W) | 40.38 | 40.55 | 40.72 | 40.89 | 41.06 | 41.22 |
| Maximum Power Current(Imp/A) | 14.99 | 15.05 | 15.11 | 15.17 | 15.23 | 15.29 |
| Open Crcuit Voltage(Voc/V) | 48.46 | 48.62 | 48.78 | 48.94 | 49.10 | 49.26 |
| Short Circuit Current(Isc/A) | 15.95 | 16.02 | 16.09 | 16.16 | 16.23 | 16.30 |
| Module Efficiency(%) | 22.40 | 22.58 | 22.77 | 22.95 | 23.14 | 23.32 |
| Power Output Tolerance(W) | 0~+5% | |||||
| ELECTRICAL SPECIFICATION(NOCT) | ||||||
| Maximum Power(Pmax/W) | 457 | 461 | 464 | 468 | 472 | 476 |
| Maximum Power Voltage(Vmp/W) | 37.70 | 37.84 | 38.00 | 38.11 | 38.24 | 38.36 |
| Maximum Power Current(Imp/A) | 12.13 | 12.18 | 12.23 | 12.30 | 12.35 | 12.41 |
| Open Circuit Votage(Voc/V) | 46.05 | 46.20 | 46.35 | 46.51 | 46.66 | 46.81 |
| Short Circuit Current(Isc/A) | 12.86 | 12.91 | 12.97 | 13.03 | 13.08 | 13.14 |
| MECHANICAL DATA | |
| Number of Cells | 132 piece |
| Dimensions of Module L*W*H(mm) | 2382*1134*30 |
| Weight(kg) | 28.2 |
| Front Side Glass | 3.2mm, Anti-reflection coating glass |
| Cell Type | Mono crysytlline |
| Frame | Anodized Aluminium |
| J-Box | IP68 Rated |
| Cable | 4.0mm², +300mm/-300mm; or Customize |
| Max Sysyem Volt(V) | 1500V DC |
| Max Fuse Rae(A) | 30 |
| Connector | MC4 compatible |
