JM Surface Emergency Keluar Sign TR218C

The JM Surface Emergency Keluar Sign (Model: TR218C) is a high-efficiency, BOMBA Approved emergency exit lighting solution engineered for commercial, industrial, and residential premises across Malaysia. Featuring an ultra-durable anodised aluminium housing, low-energy SMD LED lamps, and a certified 3+ hour battery backup, the TR218C guarantees full compliance with standard Malaysian Fire and Safety Regulations (MS983, MS619, MS IEC 60598-1). It is designed for seamless wall or ceiling mounting to maintain continuous visibility during emergency power outages.

Full Description:

Ensure your building complies with Malaysian safety codes with the JM Surface Emergency Keluar Sign - TR218C. Designed for heavy-duty commercial setups, retail outlets, factories, and high-rise developments, this surface-mounted exit light delivers bright, reliable illumination when you need it most.

Full Fire Department & Regulatory Compliance

Fire safety inspections require non-negotiable adherence to local laws. The JM TR218C carries full BOMBA Approval and complies with key Malaysian Standards:

MS983:2004 – Emergency lighting performance standard.
MS619-2-22:2012 – Specific requirements for emergency lighting luminaires.
MS IEC 60598-1:2012 – Electrical safety for lighting fittings.

Energy-Efficient Maintained LED Operation

Operating on a Maintained mode, the sign remains continuously illuminated during normal mains electricity supply and automatically transitions to internal battery power during a blackout. Equipped with 16 × SMD LEDs (16 x 0.2W SMD LED in emergency mode), the light consumes less than 6.3VA, keeping electrical bills low while offering superior luminosity and uniform light output.

Long-Lasting Battery Backup & Protection

Power outages are unpredictable, but your exit markers shouldn't be. The built-in Sealed Nickel-Cadmium (Ni-Cd) Battery guarantees a rated emergency operating duration exceeding 3 Hours. An integrated Low Voltage Cut-off safety feature automatically disconnects the battery before complete depletion, preventing over-discharge and extending overall battery lifespan. A front-facing Red LED Charging Monitor keeps facilities managers updated on the unit's charge state at a glance.

Heavy-Duty Anodised Aluminium Casing

Built to withstand commercial wear and tear, the casing is constructed from high-grade Anodised Aluminium Extrusion. With an IP20 ingress protection rating, it offers strong defense against dust and debris while maintaining a modern, professional visual aesthetic.

Specifications

Model: TR218C
Mode of Operation: Maintainec
Input Voltage: 240V±10% 50Hz
Power Consumption: <6.3VA
Battery Type: Sealed Nickel-Cadmium Battery
Lamp Used: SMD LED
Lamp-Mains ''ON'': 16 × SMD LED
Lamp-Main ''OFF'': 16 × 0.2W SMD LED
Rated Duration:>3 Hours
Housing: Andolised Aluminium Extrusion
Changing Monitor: Red LED Indicates Battery Charging
Projection Rating: IP20
Safety Feature: Low Voltage Cut-off to Prevent Over Discharge of the Battery
Mounting Type: Wall or Ceiling Mounting
Certified Compliance: MS983:2004 , MS619-2-22:2012 , MS IEC 60598-1:2012 , BOMBA APPROVED
Dimension Keluar: 538(L)mm × 198(W)mm × 125(H)mm
Outer Box: 578(L)mm × 43(W)mm × 245(H)mm
Inner Box: 555(L)mm × 40(W)mm × 235(H)mm

Q1: Is the JM TR218C Keluar Sign BOMBA approved in Malaysia?
A: Yes, the JM TR218C Emergency Keluar Sign is fully BOMBA approved and certified compliant with Malaysian Standards MS983:2004, MS619-2-22:2012, and MS IEC 60598-1:2012 for commercial premise safety regulations.

Q2: How long does the battery last during a power blackout?
A: The JM TR218C features a sealed Nickel-Cadmium battery that provides a rated backup duration of more than 3 hours during power failures.

Q3: What is the difference between Maintained and Non-Maintained emergency lights?
A:A Maintained emergency sign (like the TR218C) stays illuminated continuously during normal power supply and stays lit during a power outage. Non-Maintained lights only turn on when normal mains power fails.

Q4: Can the JM TR218C exit sign be mounted on both walls and ceilings?
A: Yes, the unit is designed for versatile surface-mounting applications and can be installed on either walls or ceilings.

Q5: What safety features prevent the battery from degrading quickly?
A: The sign incorporates an automatic Low Voltage Cut-Off circuit that disconnects the battery before it completely drains, shielding it from over-discharge damage.

Q6: How do I know if the JM TR218C is charging properly?
A: The sign includes an integrated red LED indicator on the casing that illuminates to signal active battery charging.

Q7: Does this exit sign consume a lot of electricity?
A:No, the JM TR218C uses energy-efficient SMD LEDs with a very low power consumption rating of under 6.3VA.

Q8: What housing material is used for the JM TR218C fixture?
A:It is constructed with durable, corrosion-resistant Anodised Aluminium Extrusion, delivering a sleek finish and an IP20 protection rating.

Q9: Why is SIRIM and BOMBA certification critical for exit lights in Malaysia?
A:Non-certified emergency exit lights risk failing building fire safety audits, leading to severe legal fines, delayed business operations, or denied insurance claims during emergency incidents.
