ThinkCar Four Post Alignment TVL440

当前有货

详情

features

·Pneumatic synchronous unlocking.
·Pillar design, easy to install.
·The platform is made of bent steel plates and the beams are made of square tubes.
·The cylinder adopts front fixation style to eliminate the risk of cylinder breakage.
·The platform spacing is adjustable to adapt to vehicles with different tire spacing.
·Cylinder 100% pressure holding test.
·CE certificate.
·The slider is detachable and easy to replace.
·The cable and oil pipes are fully covered.

Specifications

Rated load

4000kg

Lifting height

1700mm+400mm

Initial height

180 mm

Lifting time

≤50s

Lowering time

≥40s

Platform length

4500mm

Platform width

488mm

Power

2.2kw

Voltage

220V/380V

Hydraulic Oil

10L( Winter: N32# Summer: N46# )

Net weight

1200kg

Working Temperature

5-40℃

Air Pressure

0.6-0.8Mpa
