PT450

HD High-Performance Thermal Camera

PT II series Flagship Edition Megapixel Thermal Imager of Guide Sensmart  incorporates a new generation of self-developed uncooled infrared focal plane detector, achieving a resolution of up to 1280×1024. Its exclusive A/M-Focus manual/automatic hybrid focusing system delivers superior image quality and enhanced operational flexibility. The PT Series has undergone comprehensive upgrades in hardware configuration, software systems, and user experience, aiming to establish a new industry benchmark.

480×360IR resolution

1-lens TwinViewDFOV

Charges to 90%in 1 Hour

Up to 2500°CTemperature Range


TwinView DFoV Lens:

Switch seamlessly between long-range scanning and close-range temperature measurement without lens changes-efficiently tackling diverse scenarios with unmatched versatility.


50Hz High Frame Rate:

50Hz frame rate captures thermal dynamics instantly, ensuring zero missed detections in industrial inspections.


90% Charge in 1 Hour:

Charge to 90% in 1 hour, minimizing downtime for critical missions.

2500℃ Ultra-High Temp:

Covers -40°℃ to 2500℃, delivering accuracy from freezing cold to molten furnaces, ensuring error-free measurements in environments like kilns and reactors.

5 Focus Modes:

5 focus modes and rapid focus system boost success rates by 90% in complex scenarios.

PerIRVision Panoramic Stitching:

AI-powered stitching improves large-area thermal scanning efficiency by 80% for substations, buildings, and more.
