• Accessory
– Movable stainless wire shelves 2EA
• Option
– Programmable controller
– Digital recorder
– 2CH Hybrid recorder
– RS-485 interface
– RS-232C interface
• Safety Device
– Automatic reset function incoming power cut
– Buzzer on when set time arrived
– Door open alarm
– Electric leakage breaker
– Over temp function
– Fire safety controller
|
Model |
SH-DO-54FG |
| Air Circulation type |
Forced |
|
Temp Range |
Ambient +10℃ to 250℃ (Ambient +18! to 482! ) |
| Time Range |
00.00 to 99HR 59MIN (MIN SEC) Selectable Digital Counter Timer |
|
Temp & Time controller |
Microprocess PID Membrane Touch Digital controller |
| Heater Capa |
800 W |
|
Dimension Internal (W×D×H) |
380×340×420mm
14.96×13.39×16.54” |
| Dimension External
(W×D×H) |
500x630x760mm 19.68×24.80×29.92” |
|
Weight |
49 kg |
| Capa |
54 L |
|
Material Internal |
Stainless Steel |
|
Material External |
Steel Plate With Powder Heating Coated |
| Shelves |
2 Supplied (12 Maximum) |
|
Fan Position |
Rear |
| Electrical Requirements
120V ,50/60Hz, 1Φ |
7.3 A |
|
Cat. No. |
DO54FG120 |
| Electrical Requirements
230V,50/60Hz, 1Φ |
3.5 A |
|
Cat. No. |
DO54FG230 |
Forced Convection Drying Oven is commonly used in laboratories and other related industries for the purpose of sample drying and sterilization. It also comes with outstanding features such as high level of temp. uniformity, precise accuracy and stable temperature control. All of these are possible through our advanced technology and continuous innovation.
