G300 - G SERIES AUTO VISION MEASURING SYSTEM

Features:

• Granite base and pillar, good stability.
• Moving Column type structure, measuring workpiece is fixed.
• Gige high-resolution digital camera, to ensure clear image without distortion.
• High-resolution motorized coaxial zoom lens, accurate doubling and one times pixel correction only needed.
• Brand linear scale, resolution is 0.1um, grinding ball screw and AC servo motor etc. to ensure the precision and stability of the motion system.
• With programmable surface 7-ring 8-division LED Cold Illumination and contour LED parallel illumination and built-in intelligent light adjustment, it can automatic control the brightness in the 8-division.
• Four-axis CNC fully auto close loop control, auto measurement.
