Chem-Max YB65 Diesel Vane Pump / YB65 Vane Pump: 马来西亚的首选 Boston Industrial Engineering Sdn Bhd

Chem-Max YB series rotary vane pumps are self priming pump known for their efficiency in handling viscous and volatile liquids, often found in applications like fuel oil delivery and petrochemical transport. They feature a rotor with sliding vanes, constructed with nodular iron and self-lubricating materials. These pumps are recognized for their ability to achieve high flow rates at lower rotational speeds compared to other designs and are equipped with internal bypass valve for pressure relief.

Key Features and Design:

Sliding Vane Design:

The core of the pump's operation lies in the sliding vanes that move within the rotor to create chambers of varying sizes, drawing in and pushing out the liquid.
Self-Priming:

This feature allows the pump to automatically draw liquid into the pump chamber without requiring manual priming, simplifying operation.
Internal Bypass Valve:

This valve helps regulate pressure within the pump, preventing damage from excessive pressure buildup.
Durable Construction:

The use of nodular iron for the pump body and self-lubricating materials for the vanes ensures the pump's longevity and resistance to wear.
Efficiency:

The design allows for high flow rates at lower rotational speeds, reducing energy consumption and wear.

Applications:

Fuel Oil Delivery:

These pumps are commonly used in trucks for delivering fuel oil to various locations.
Fleet Refueling:

They are suitable for refueling vehicles in fleet operations.
Lube Oil and Aviation Refueling:

YB pumps are also used in the transfer of lubricating oils and aviation fuels.
Petrochemical Transport:

Their ability to handle volatile liquids makes them suitable for transporting petrochemicals.

General Liquid Transfer:

They can be used for various other applications requiring the transfer of liquids

Model	Pump Size	Flow rate	Flow rate	Flow rate	Flow rate	Flow rate	Flow rate
		650rpm	600rpm	550rpm	500rpm	450rpm	400rpm
		G/M(L/M)	G/M(L/M)	G/M(L/M)	G/M(L/M)	G/M(L/M)	G/M(L/M)
YPUMP-YB-50	2''	80(300)	72(270)	64(240)	56(210)	48(180)	40(150)
YPUMP-YB-65	2.5''	132(500)	123(456)	114(430)	103(390)	93(350)	82(310)
YPUMP-YB-80	3''	265(1000)	243(920)	222(840)	200(760)	180(680)	160(160)
YPUMP-YB-100	4''	-	-	-	505(1900)	-	405(1530)

PUMP MODEL	RATED PUMP SPEED	hp	kW	WEIGHT	PACKING
YPUMP-YB-50	640RPM	3	2.2	34KG	44X33X39
YPUMU-YB-65	640RPM	5	4	40KG	44X33X39
YPUMP-YB-80	640RPM	10	7.5	64KG	45X40X38
YPUMP-YB-100	500RPM	25	18.5	160KG	54X49X58
