Description

Tohnichi RNTD Torque Screwdriver

Preset torque screwdriver with rotary-slip mechanism to prevent over-tightening.

RNTD60CN [Overall length 94 mm]

RNTD120CN [Overall length 109 mm]

RNTD500CN with an auxiliary handle (supplied)

The RNTD series is equipped with Tohnichi’s own toggle mechanism for torque control.



The bit on the picture is optional.

Application

  • Used for repeated preset torque tightening during mass production and maintenance.

Features

  • Same features as RTD except designed for tightening small screws.
  • Preset style.
  • Enhanced reliability and durability by adopting toggle clutch torque mechanism.
  • RTD is designed to ratchet freely after reaching the set torque to prevent applying over-torque.
  • Preset style is ideal for applications which requires the same torque value on the line.
  • RNTD500CN comes with an auxiliary handle.
  • Counterclockwise tightening model available upon request. Please contact us.

Specifications

                    Accuracy ± 3%
MODEL RNTD15CN RNTD30CN RNTD60CN RNTD120CN RNTD260CN RNTD500CN
TORQUE RANGE
[cNem]		 MIN.MAX. 515 1030 2060 40120 100260 200500
TORQUERANGE
[kgfecm]		 MIN.MAX. 0.51.5 13 26 412 1026 2050
TORQUE RANGE
[lbfein]		 MIN.MAX. 0.51.3 12.5 25 410 1022 2040
APPLICABLE SCREW SMALL SCREW M1.8 M2M2.2 M2.5, M3 M3.5 M4M4.5 M5, M6
TAPPING SCREW M1.4M1.6 M1.8M2 M2.2M2.5 M3M3.5 M4 M4.5
DIMENSION
[mm]		 OVERALL LENGTH L' 94 109 110 119
GRIP D1 19.5 24 30.5 33
BODY COLOR Black
BODY D4 11
L1 24
L2 59 76 79 88
HANDLE d 0 8
R 0 120
WEIGHT [kg] 0.07 0.11 0.18 0.27

Standard accessory

Comes with resin handle (for RNTD120CN and RNTD260CN only).

RNTD500CN comes with an auxiliary handle.

Dimensions

Expand dimensions

RNTD15CN260CN

RNTD500CN
