 Sensor |
|---|
|
Sensor type
Paddle wheel / oval gear
|
|
Paddle wheel measuring principle detection
Hall
|
 Measurand |
|---|
|
Flow rate (volume)
Yes
|
|
Flow rate (mass)
No
|
|
Temperature
No
|
|
Density
No
|
|
Concentration 1
No
|
|
Precision of volume flow rate in relation to reading
1 %
|
 Voltage / Frequency |
|---|
|
Battery voltage
No
|
|
DC voltage min
12 V
|
|
DC voltage max
36 V
|
 Materials |
|---|
|
Cover material
PC (polycarbonate)
|
|
Electronics body material category
Plastics
|
|
Electronics body material
PC (Polycarbonate)
|
|
Electronics body encapsulated
Resin
|
 Process Pressure / Temperature |
|---|
|
Temperature medium min
-15 °C
|
|
Temperature medium max
100 °C
|
|
Temperature environment min
-15 °C
|
|
Temperature environment max
60 °C
|
 Input / Output |
|---|
|
Output 1 digital type
Transistor
|
|
Digital output 1 transistor contactless
0,1 A
|
|
Output 1 digital transistor connection NPN
Yes
|
|
Output 1 digital transistor connection PNP
No
|
|
Output 2 digital type
Transistor
|
|
Output 2 digital transistor connection NPN
No
|
|
Output 2 digital transistor connection PNP
Yes
|
|
Digital output 2 transistor contactless
0,1 A
|
 Features |
|---|
|
Continuous measurement
Yes
|
|
Dosing
No
|
|
Switch
No
|
|
Parametrisation local
No
|
|
Parametrisation separate
No
|
|
Parametrisation fixed
No
|
 Properties |
|---|
|
Type
SE30
|
|
Product sub-group
Flow rate
|
|
Construction device
Bayonet
|
 Elektronic |
|---|
|
Fitting electronic interface
Inline
|
 Electrical Port Connection |
|---|
|
Electrical connection 1 type
Plug pattern form A according to DIN EN 175301-803
|
|
Electrical connection 1 quantity
1 PCE
|
|
Electrical connection 1 number of contacts
4 PCE
|
|
Cable plug in delivery
enclosed
|
|
Cable plug art. no. - type
00572264 - 2518
|
 Software / Communication |
|---|
|
Display type
no display
|
 Protection Type |
|---|
|
Protection class measurement device (IP)
IP65
|
