LFH52 Temperature & Humidity Transmiter is specially designed for outdoor temperature and humidity detection.
The Radiation Cover can protect from wind and rain, and provide the best protection for the transmitter in severe weather.
There are 3 output modes of current, voltage and RS485 available. Can be used in construction sites, weather monitoring and other outdoor occasions.
| RELATIVE HUMIDITY | |
| Sensor | Digital |
| Measuring Range | 0%~100%RH |
| Output | RS485/Modbus, 0~10VDC, 4~20mA optional |
| Accuracy | ±3%@ 20℃ & 20 ~ 80%RH |
| TEMPERATURE | |
| Sensor | Digital or RTD |
| Measuring Range | 0~50℃, -20~60℃, etc |
| Output | RS485/Modbus, 0~10VDC optional |
| Work Temperature | -20~60°C, 5%-95%RH (non-condensing) |
| Thermal Resistance | Refer Selection Guide |
| Output Load |
≤500Ω(current type) ≥2KΩ(voltage type) |
| Accuracy |
Digital sensor: ±0.3℃@20℃ RTD: Typical ±0.2~0.4℃@25℃, refer to selection table |
| Power Supply |
Voltage type/485 type 15-35VDC/24VAC±20% (isolated power suply is required for AC power supply) Current type 18.5~35VDC (RL=500Q) 8.5~35VDC (RL=0Ω) |
| Shell Material | PC shell, PA6 probe rod,ABS protective cover |
| Protection Grade | IP65 |
|
Code and Description |
Remark |
|||||||
|
LFH52 |
Outdoor Temperature and Humidity Transmitter |
Model |
||||||
| 3 | ±3%RH(±0.5℃) |
Accuracy |
||||||
| V10 | 0~10VDC(Three-wired) |
Humidity output |
||||||
| A4 | 4~20mA (Two-wired) | |||||||
| RS | RS485/Modbus | |||||||
| V10 | 0~10VDC(Three-wired) |
Temperature Output |
||||||
| A4 | 4~20mA(Two-wired) | |||||||
| RS | RS485/Modbus | |||||||
| 0 | PT1000，±0.2℃@0℃ | |||||||
| 1 | PT100，±0.2℃@0℃ | |||||||
| 2 | NTC20K, ±0.4℃@25℃ | |||||||
| 6 | NTC10K, ±0.4℃@25℃ | |||||||
| 0 | Non | Temperature Range | ||||||
| 1 |
0~50℃ |
|||||||
| 2 |
-20~60 |
|||||||
| 8 |
Customizable |
|||||||
|
LFH52 |
3 | A4 | A4 | 2 |
Selection example |
|||
