LFH70 Temperature & humidity Transmitter is a highly reliable product developed for high-precision temperature and humidity measurement in fundamental industrial applications and climate control fields.
Its split probe can work in environments with temperatures up to 180 °C.
The high-temperature humidity sensitive capacitor has high long-term stability, strong anti pollution ability, and excellent anti electromagnetic interference ability.
Comparing to other HVAC transmitters, the innovative metal structure design gives LFH70 the advantage of stronger structure and and longer duration in harsh working conditions.
| RELATIVE HUMIDITY | |
| Sensor | High temp & humidity sensitive capacitor |
| Measuring Range | 0%~100%RH |
| Output | RS485/Modbus, 0~10VDC, 4~20mA optional |
| Response Time | ≤10S |
| Accuracy |
≤90%RH@20°C ±2%RH ≥90%RH@20°C ±2.3%RH |
| TEMPERATURE | |
| Sensor | PT1000 |
| Probe Operating Temperature | -40~180°C |
| Operating temperature range of electronic components (with LCD) | -20~60°C |
| Output | RS485, 0-10V, 4-20mA optional |
| Output Load |
≤500Ω(current type) ≥10KΩ(voltage type) |
| Accuracy | ±0.2℃@20℃ (Refer Accuracy Curve Chart) |
| Power Supply | 15-35VDC/24VAC ±20% |
| Relay | 2×SPDT (3A-30VDC/250VAC) |
| Shell Material | PC shell, PA6 probe rod, ABS protective cover |
