Features
- Unmatched cutting smoothness and durable precision.
- Extreme cutting smoothness because of innovative and maintenance-free gliding system.
- Integrated dual line laser supports accurate cuts.
- High vertical and horizontal cutting capacity.
- Lasting precision due to innovative, maintenance-free and extremely robust guide arm.
- Frictionless slide mechanism ensures very easy sawing without loss of power.
- Accurate cuts and the highest cut quality due to integrated double line laser and Top Precision Best for Wood saw blade.
- Efficient dust extraction due to optimised suction spouts.
- All controls for mitre and bevel settings are situated on the front of the machine to make work more convenient.
- Pull-out material supports integrated on the right and left with integrated length stop.
- Integrated carrying handle for easy transport.
- Compact slide mechanism enables space-saving positioning directly against the wall.
- Powerful motor (2000 watts) offers sufficient power reserves for thick woods.
- Groove-cutting function.
Description
- Mitre setting: 52 ° L / 60 ° R
- Saw blade diameter: 305 mm
- Bevel setting: 47 ° L / 47 ° R
- Rated input power: 2,000 W
- Cutting capacity, 0°: 104 x 341 mm
- Cutting capacity, 45° mitre: 104 x 240 mm
- Cutting capacity, 45° bevel: 51 x 341 mm
- Tool dimensions (width x length x height): 1100 x670 x740 mm
- No-load speed: 4,000 rpm
- Saw blade bore diameter: 30 mm
- Weight: 32.1 kg
Total vibration values (Sawing wood)
- Vibration emission value ah: 2.5 m/s²
- Uncertainty K: 1.5 m/s²
Noise/vibration information
- Sound pressure level: 93 dB(A)
- Sound power level: 106 dB(A)
- Uncertainty K: 3 dB
Sawing wood
- Vibration emission value ah: 2.5 m/s²
- Uncertainty K: 1.5 m/s²
Package Includes:
- 1 x GCM 12 GDL Professional Mitre Saw
- 1 x Collet
- 1 x Insert plate
- 1 x Internal hexagon
- 1 x Circular saw blade, Expert for Wood, 305 x 30 x 2.4 mm
