LINGGAO High End AI Series K3000

Model :


• K3000

• Frequency/Power: 20kHz 2000W/3000W
• Multiple language options
• Scan data via barcode or QRcode
• Unique welding pressure segmented control
• Record welding parameters via USB barcode storage
• 8 welding modes, 2 trigger modes
• The descending speed is adjustable with a scale display, and one circle can control the full open/full close function
• The working stroke is 20~100mm, no need to adjust the machine height, and it is equipped with a stop limit switch.
• Hierarchical password protection and network connection to master welding parameter specifications
• Digital amplitude setting and amplitude segmentation function
• The dovetail groove with locking structure design prevents bending resistance about 7.8 times that of the cylinder to prevent backward movement, and the downward pressure recovery mechanism does not deviate
• Modular design, in line with the integration of industrialization and information technology, Industry 4.0
• Electromagnetic sensor precision stroke measurement kit, welding accuracy ≤ 0.01mm
• Using slide rails, the welding head can be raised and lowered smoothly and stably
• Height indication uses high-precision electronic ruler for real-time measurement (resolution 0.005mm)
• Can monitor the quality of finished workpieces, reduce manual inspections, and improve work efficiency
• The electric box alarm exceeds the set range value
• World-class pneumatic accessories, available for global purchase and good interchangeability
• Comply with European CE safety standards, independent intellectual property rights are protected by law, and can avoid legal disputes
• Four-point bottom adjustment level design with scale for easy calibration
• Special steel horizontal plate, stable and resistant to deformation, large machine tool T-slot, easy to adjust
