Specifications
- Application:
REDLINE is installed to play critical integral role in various fire protection systems in buildings and facilities.
FIRE SPRINKLER SYSTEMS
| It is hydraulically designed in accordance with the relevant hazard class to
provide anappropriate density of discharge over an assumed area of protection. When the system is
activated, and adequate water supply and pressure is required, REDLINE is typically installed to meet
this hydraulic demand.
Fire Sprinkler Systems are classified on the basis of the hazard classes of occupancies. MONOFLO’s
AS2941:2013-compliance REDLINE End Suction Pumps meet these requirements - the Ordinary Hazard
Class for fire sprinkler systems, from OH Group 1, 2 & 3, to OH Group Special Class.
HYDRANT & WET RISER SYSTEMS
| REDLINE offers high-head models, capable of lifting water to
higher floor levels in a typical Hydrant or Wet Riser Systems in buildings, serving landing valves,
canvas hoses and hose reels.
- Design Features:
MEETING HYDRAULIC REQUIREMENTS IN THE CLASSIFICATION OF OCCUPANCIES-HAZARD (OH) GROUPS, FOR A SPRINKLER SYSTEM
| The comprehensive range of End Suction Pumps - Model RLS, performs in accordance to AS2941.
It is designed to meet a range of flowrates required in the various hazard group classifications - the Ordinary Hazard
Class for fire sprinkler systems, from OH Group 1, 2 & 3, to OH Group Special Class and Extra High Hazard.
END SUCTION ‘BACK PULLOUT’ PUMPS
| Manufactured in high grade cast iron, this ISO2858 end suction pump is of centerline discharge design
for automatic self-venting. The casing volute is CFD-aided designed, giving optimal hydraulic performance and operation reliability.
The impellers, which are dynamically balanced, are of enclosed type.
Replaceable wear rings are fitted as standard.
The pump shaft is fitted with a protecting sleeve, and is supported by an angular thrust type bearing at the hydraulic-end;
and a single row deep-grooved ball bearing at the coupling-end.
The pump features a “back pullout "design which allows the whole hydraulic assembly to be
removed from the pump casing for maintenance and service without disturbing the pipework.
The mounting feet is integrally casted to the casing.
PACKAGED SYSTEM
| REDLINE can be supplied in a factory-assembled packaged fire unit comprising the pump, its driver (electric motor
or diesel engine) and a controller, mounted on a common frame as an integral system.
Accessories are optional.
Description
REDLINE. A properly designed, installed and maintained automatic fire protection system
helps save lives and properties.
As a chain is as strong as its weakest link, the fire pumps
has to be as reliable a component as the other equipment in the fire protection system
to ensure the credibility in protecting lives and properties.
Hence, compromising in the design of MONOFLO ‘REDLINE’ fire-fighting pumps and pumpsets, is not an option.
Build to ISO2858 standard, the REDLINE End Suction pumps meet the latest AS2941:2013 guidelines,
is specific in its design for requirements in fire protection systems, particularly in the
Fire Sprinkler Systems and the Hydrant & Wet Riser System.
The CFD-aided designed pumps is robust in build, and have optimal hydraulic performance and high in operation reliability.
.png)
.png)
