| Specification | |
| Fluid medium | Air, Water (Conditional*) |
| Max. operating pressure | 1.0MPa |
| Max. vacuum | -100kPa |
| Operating temp. range | 0~60ºC (No freezing) |
| Applicable size | |
| ■Tube diameter | |
| MM size (mm) | ø4, ø6, ø8, ø10, ø12, ø16 |
| Inch size | ø1/8, ø5/32, ø3/16, ø1/4, ø5/16, ø3/8, ø1/2, ø5/8 |
| ■Thread size | |
| Metric size | M5×0.8, M6×1 |
| Taper pipe thread | R1/8, R1/4, R3/8, R1/2 |
| Metric thread | M5×0.8 |
| Taper pipe female thread | Rc1/8, Rc1/4, Rc3/8, Rc1/2 |
