Features
| Model | CBD30 |
|
Capacity Q (kg) |
3000 |
|
Load Center C (mm) |
600 |
| Type of Lifting | Electric |
| Operating Type | Walkie / Stand |
| Material of Wheel | PU |
|
Wheel Base Y (mm) |
1500 |
|
Quantity Drive / Balance / Bearing |
1 x + 2/4 |
|
Bearing Wheel Size (mm) |
Փ 80 x 70 |
|
Drive Wheel Size (mm) |
Փ 230 x 75 |
|
Balance Wheel Size (mm) |
Փ 100 x 50 |
|
Minimum Fork Height H13 (mm) |
85 |
|
Maximum Fork Height (mm) |
200 |
|
Max. Lifting Height H3 (mm) |
115 |
|
Outer Fork Width (mm) |
560 / 685 |
|
Inner Fork Width (mm) |
200 / 325 |
|
Fork Length L (mm) |
1150 |
|
Single Fork Size e/s (mm) |
180 / 60 |
|
Overall Length L1 (mm) |
2300 |
|
Overall Width B (mm) |
800 |
|
Overall Height (mm) |
1355 |
|
Handle Vertical Height ( Min / Max ) H14 (mm) |
1040 / 1355 |
|
Minimum Turning Radius Wa (mm) |
1745 |
|
Travel Speed (Laden / Unladen) (km/h) |
5 / 6 |
|
Lifting Speed (Laden / Unladen) 9mm/s) |
21.6 / 35.5 |
|
Lowering Speed (Laden / Unladen) (mm/s) |
28.6 / 25 |
| Adjustment of Speed (Fast / Slow) | Yes |
|
Gradebility (%) |
6 |
| Drive Mode | AC |
|
Drive Motor (kw) |
24V2.5 |
|
Lift Motor (kw) |
24V2.2 |
|
Battery Capacity (V/Ah) |
24V / 280 |
| Charger | 24V30A |
|
Battery Weight (kg) |
250 |
|
Net Weight (kg) |
750 |
