| Product ID |
MP-270 |
| Technology |
Full contact technology with magnetic knife-shaped probe wheel |
| Profile Accuracy |
Better than ±11.0 μm |
| Repeatability |
±2.5 μm |
| Gauge |
≤ 200 μm |
| Measuring Speed |
< 5 seconds per profile |
| Horizontal Movement Range |
300 mm (100 mm gauge side, 200 mm field side) |
| Displacement |
≤ 100 μm |
| Operating Temperature |
-15°C to +50°C |
| S&C Unit Weight/Dimensions |
7.0 kg (1769 x 184 x 171 mm) |
| Transport Case Weight/Dimensions |
10.0 kg (740 x 300 x 270 mm) |
| Software |
Full Envision software package, 5 installations |
| Warranty |
2 years standard, extendable to 10 years |
