Brand: KAAS
Model: MSC-ST60
Product Type: Binocular Stereo Microscope
Application: PCB inspection, electronics inspection, laboratory observation, component assembly and industrial quality control
The KAAS Binocular Stereo Microscope is designed for routine visual inspection, three-dimensional observation and precision handling of solid specimens in laboratories, manufacturing facilities, educational institutions and technical workshops.
The microscope provides a clear stereoscopic image with good depth perception, allowing operators to observe the surface profile, component position, assembly condition and visible defects of small objects.
Its standard optical configuration provides 20X to 40X magnification, while an extended range of approximately 10X to 80X can be achieved using optional eyepieces and objective combinations. The binocular viewing head is inclined at 45° and can rotate through 360° for a more comfortable working position.
The KAAS MSC-ST60 is suitable for printed circuit board inspection, soldering and rework, electronic component inspection, small-part assembly, surface-defect observation, laboratory examination and general quality-control applications.
Redmark Industry Sdn Bhd supplies KAAS stereo microscopes in Malaysia with application consultation, optical configuration selection, installation, operator familiarisation and after-sales technical support.
The KAAS MSC-ST60 may be used for:
The microscope is intended primarily for visual observation. Dimensional measurement requires a compatible reticle, camera, calibration scale or measurement-software system.
◆ Standard magnification range of 20X to 40X
◆ Expandable magnification range of approximately 10X to 80X
◆ Binocular optical head for three-dimensional observation
◆ 45° inclined viewing head for improved operator comfort
◆ 360° rotatable head for flexible viewing positions
◆ Adjustable interpupillary distance from 54mm to 76mm
◆ ±5 diopter adjustment for individual eye correction
◆ Wide-field WF10X/20mm eyepieces
◆ Interchangeable eyepiece and objective configurations
◆ Shifting dual-objective system
◆ Wide-angle objective lens for a larger viewing field
◆ High-quality objective lens for clear imaging
◆ Robust pole stand for stable routine operation
◆ 50mm vertical focusing travel
◆ LED ring-light or fluorescent illumination options
◆ Even light distribution for surface inspection
◆ Durable metal-body construction
◆ Compact benchtop design
◆ Suitable for laboratories, classrooms and light industrial applications
The reference configuration specifies WF10X/20mm eyepieces, selectable 2X/4X, 1X/2X and 1X/3X objective combinations, a 45° inclined binocular head, 360° rotation and adjustable interpupillary distance.
| Parameter | Specification |
|---|---|
| Brand | KAAS |
| Model | MSC-ST60 |
| Microscope type | Binocular stereo microscope |
| Standard magnification | 20X–40X |
| Extended magnification | Approximately 10X–80X with optional optics |
| Standard eyepiece | WF10X/20mm |
| Optional eyepieces | 10X/20mm, 15X/15mm, 20X/10mm |
| Standard objective | 2X/4X |
| Alternative objectives | 1X/2X or 1X/3X |
| Viewing head | Binocular |
| Head inclination | 45° |
| Head rotation | 360° |
| Interpupillary adjustment | 54–76mm |
| Diopter adjustment | ±5 diopters |
| Focusing travel | 50mm vertical travel |
| Stand | Pole stand |
| Illumination | LED ring light or fluorescent lamp |
| Shipping dimensions | Approximately 400 × 250 × 360mm |
| Gross weight | Approximately 7kg |
These specifications are based on the referenced MSC-ST60 configuration. The final KAAS supply configuration should be confirmed in the quotation before publication or order placement.
| Eyepiece | Objective | Total Magnification |
|---|---|---|
| 10X | 1X | 10X |
| 10X | 2X | 20X |
| 10X | 3X | 30X |
| 10X | 4X | 40X |
| 15X | 1X | 15X |
| 15X | 2X | 30X |
| 15X | 4X | 60X |
| 20X | 1X | 20X |
| 20X | 2X | 40X |
| 20X | 4X | 80X |
The available magnification depends on the selected eyepiece and objective combination. Confirm the required field of view and working distance before choosing the optical setup.
For electronics applications, the KAAS MSC-ST60 can support:
A stereo microscope is particularly useful for work that requires hand-eye coordination because it provides an upright image and visible depth perception.
The KAAS MSC-ST60 is also suitable for:
The referenced unit is described for universities, clinics, laboratories, classrooms and light industrial applications requiring routine optical observation.
Depending on the confirmed KAAS package, the standard supply may include:
The final standard supply must follow the KAAS quotation and packing list.
Optional accessories should not be presented as standard inclusions unless confirmed in the commercial offer.
The KAAS MSC-ST60 is a visual observation and inspection microscope.
It should not automatically be described as a dimensional measuring microscope. Applications requiring calibrated length, angle, radius, area or coordinate measurement may require:
The required magnification should also be selected together with the field of view and working distance. Higher magnification normally produces a smaller viewing field and may reduce the available working clearance.
Redmark Industry Sdn Bhd provides local technical and commercial support for KAAS microscopes in Malaysia, including:
Send Redmark Industry details of your specimen, smallest feature to be inspected, required magnification, working distance and image-documentation requirements.
Our technical team will recommend a suitable KAAS microscope configuration for your laboratory or industrial-inspection application.
