Diamond Cutting Wheel

Precision diamond cutting wheels for controlled sample preparation with reduced heat generation and cutting-surface damage.

Product Overview

This is a "Diamond Wheel" consumable used in precision cutting machines , consisting of 4~7 inches (Arbor 12.7mm).

Diamond cutters may deform the cutting surface because of heat and friction generated during high-speed abrasive cutting.
They are suitable when minimizing heat generation during cutting is important.
Selecting the correct wheel for the sample material helps prevent unnecessary cutting damage.
Wheel selection should reduce changes in material structure and limit heat generation.
Typical wheel thickness is approximately 0.2–0.4 mm; thicker wheels increase material loss.
General and Premium product options are available, and General wheel thickness can be customized.

Item	Description	Capacity and pkg
LC (Low Concentration)	Used for cutting hard metallic ceramics and glass that are highly rigid or fragile	1ea/pkg
HC (High Concentration)	Used for cutting soft materials such as metal , plastic , and polymer
CBN (Cubic Boron Nitride)	Used for cutting extremely hard materials such as lead and titanium

General Diamond Precision Wheel		Premium Diamond Precision Wheel
Product Name	Specifications	Product Name	Specifications
MD-DW-04-LC	101mm(4”) dia x 0.5mm(T) x 12,7mm(A)	MD-DW-04-LCP	101mm(4”) dia x 0.35mm(T) x 12,7mm(A)
MD-DW-04-HC	101mm(4”) dia x 0.5mm(T) x 12,7mm(A)	MD-DW-04-HC P	101mm(4”) dia x 0.35mm(T) x 12,7mm(A)
MD-DW-04-CB	101mm(4”) dia x 0.6mm(T) x 12,7mm(A)	MD-DW-04-CB P	101mm(4”) dia x 0.35mm(T) x 12,7mm(A)
MD-DW-05-LC	127mm(5”) dia x 0.7mm(T) x 12,7mm(A)	MD-DW-05-LC P	127mm(5”) dia x 0.45mm(T) x 12,7mm(A)
MD-DW-05-HC	127mm(5”) dia x 0.7mm(T) x 12,7mm(A)	MD-DW-05-HC P	127mm(5”) dia x 0.45 mm(T) x 12,7mm(A)
MD-DW-05-CB	127mm(5”) dia x 0.6mm(T) x 12,7mm(A)	MD-DW-05-CB P	127mm(5”) dia x 0.45 mm(T) x 12,7mm(A)
MD-DW-06-LC	152mm(6”) dia x 0.7mm(T) x 12,7mm(A)	MD-DW-06-LC P	152mm(6”) dia x 0.5mm(T) x 12,7mm(A)
MD-DW-06-HC	152mm(6”) dia x 0.7mm(T) x 12,7mm(A)	MD-DW-06-HC P	152mm(6”) dia x 0.5 mm(T) x 12,7mm(A)
MD-DW-06-CB	152mm(6”) dia x 0.7mm(T) x 12,7mm(A)	MD-DW-06-CB P	152mm(6”) dia x 0.5 mm(T) x 12,7mm(A)
MD-DW-07-LC	177mm(7”) dia x 0.7mm(T) x 12,7mm(A)	MD-DW-07-LC P	177mm(7”) dia x 0.55mm(T) x 12,7mm(A)
MD-DW-07-HC	177mm(7”) dia x 0.7mm(T) x 12,7mm(A)	MD-DW-07-HC P	177mm(7”) dia x 0.55 mm(T) x 12,7mm(A)
MD-DW-07-CB	177mm(7”) dia x 0.7mm(T) x 12,7mm(A)	MD-DW-07-CB P	177mm(7”) dia x 0.55 mm(T) x 12,7mm(A)
