The Eranntex BTYQ-PTM600-CH4-TDLAS Portable Methane Analyzer's multiple alarm system supports audible, visual, vibration, or combined alarm modes, providing three-dimensional status indication. It covers three trigger types: concentration threshold, undervoltage warning, and fault alarm. Alarm modes include low limit, high limit, interval, and weighted average settings. The device is equipped with automatic zero-point tracking technology and multi-level calibration functions, effectively suppressing zero-point drift caused by long-term use and automatically intercepting concentration calibration errors. A factory reset function is standard, and an ambient temperature and humidity monitoring module or RS485 communication interface are optional. Other functional expansions and communication protocols support in-depth customization, and are fully open to OEM/ODM cooperation and development.
|
Parameter |
Specification |
|
Detected Gas |
Methane (CH ) |
|
Detection Range |
0–1000 ppm (other ranges customizable) |
|
Resolution |
0.1 ppm |
|
Detection Principle |
Laser-based (1% high accuracy, 10-year stability, no zero drift & cross-interference, long optical path & high resolution) |
|
Typical Accuracy |
≤±2% F.S. (higher accuracy customizable) |
|
Linearity |
≤±2% |
|
Repeatability |
≤±2% |
|
Uncertainty |
≤±2% |
|
Response Time (T90) |
≤20 seconds |
|
Recovery Time |
≤30 seconds |
|
Operating Environment |
Temp: -20 to +55 (typical), -40 to +70 (extreme); Humidity: ≤95% RH (non-condensing);<br>High-temp sampling handle optional |
|
Temp/Humidity (Optional) |
Temp: -40~+70 (±0.5); Humidity: 0–100% RH (±3% RH) |
|
Power Supply |
3.8 VDC, dual 5400 mAh rechargeable polymer batteries |
|
Display |
3.5-inch HD color screen, 8-key operation |
|
Sampling Method |
Built-in pump suction (800 ml/min flow rate) |
|
Communication |
USB (charging & data), optional RS485, infrared |
|
Data Storage |
100,000 data records standard (custom capacity available) |
|
Protection Rating |
IP66 |
|
Explosion Proof Rating |
Intrinsically Safe: Exia II C T4 Ga / Exia D20 T130 |
|
Dimensions |
420 × 210 × 125 mm (L×H×W) |
|
Weight |
3.2 kg (slight variations by configuration) |
All-in-one interface
single gas interface
curve display interface
(The all-in-one interface is not available for single gas detection)
The Eranntex BTYQ-PTM600-CH4-TDLAS Portable Methane Analyzer optional accessories: (Optional accessories require additional charges)
High humidity filter
telescopic sampling handle
High-temperature sampling handle
(0.3m 400°C/0.7m 800°C/1.2m 1300°C; three sizes available)
|
Detected Gas |
Range(s) |
|
Combustible Gas (EX) |
0-100% LEL, 0-100% Vol |
|
Methane (CH ) |
0-100% LEL, 0-100% Vol, 0-1000 ppm, 0-10000 ppm |
|
Oxygen (O ) |
0-30% Vol, 0-100% Vol, 0-5000 ppm |
|
Nitrogen (N ) |
0-100% Vol |
|
Carbon Monoxide (CO) |
0-100 ppm, 0-1000 ppm, 0-2000 ppm, 0-20000 ppm, 0-100000 ppm |
|
Carbon Dioxide (CO ) |
0-500 ppm, 0-2000 ppm, 0-5000 ppm, 0-50000 ppm, 0-20% Vol, 0-100% Vol |
|
Formaldehyde (CH O) |
0-10 ppm, 0-100 ppm, 0-1000 ppm |
|
Ozone (O ) |
0-1 ppm, 0-5 ppm, 0-50 ppm, 0-100 ppm, 0-2000 ppm, 0-30000 ppm |
|
Hydrogen Sulfide (H S) |
0-10 ppm, 0-50 ppm, 0-100 ppm, 0-2000 ppm, 0-10000 ppm |
|
Sulfur Dioxide (SO ) |
0-10 ppm, 0-20 ppm, 0-100 ppm, 0-500 ppm, 0-2000 ppm, 0-10000 ppm |
|
Nitric Oxide (NO) |
0-10 ppm, 0-100 ppm, 0-2000 ppm, 0-5000 ppm |
|
Nitrogen Dioxide (NO ) |
0-10 ppm, 0-100 ppm, 0-2000 ppm, 0-5000 ppm |
|
Nitrogen Oxides (NOx) |
0-10 ppm, 0-100 ppm, 0-2000 ppm, 0-5000 ppm |
|
Chlorine (Cl ) |
0-10 ppm, 0-20 ppm, 0-200 ppm, 0-2000 ppm |
|
Ammonia (NH ) |
0-10 ppm, 0-100 ppm, 0-1000 ppm, 0-5000 ppm, 0-100% LEL |
|
Hydrogen (H ) |
0-100% LEL, 0-1000 ppm, 0-20000 ppm, 0-40000 ppm, 0-100% Vol |
|
Helium (He) |
0-100% Vol |
|
Argon (Ar) |
0-100% Vol |
|
Xenon (Xe) |
0-100% Vol |
|
Hydrogen Cyanide (HCN) |
0-30 ppm, 0-100 ppm |
|
Hydrogen Chloride (HCl) |
0-20 ppm, 0-200 ppm |
|
Phosphine (PH ) |
0-10 ppm, 0-100 ppm, 0-1000 ppm, 0-4000 ppm |
|
Chlorine Dioxide (ClO ) |
0-1 ppm, 0-10 ppm, 0-200 ppm |
|
Ethylene Oxide (ETO) |
0-100 ppm, 0-1000 ppm, 0-100% LEL |
|
Phosgene (COCl ) |
0-1 ppm, 0-50 ppm |
|
Silane (SiH ) |
0-1 ppm, 0-50 ppm |
|
Fluorine (F ) |
0-1 ppm, 0-10 ppm, 0-50 ppm |
|
Hydrogen Fluoride (HF) |
0-10 ppm, 0-50 ppm |
|
Hydrogen Bromide (HBr) |
0-50 ppm |
|
Diborane (B H ) |
0-10 ppm |
|
Arsine (AsH ) |
0-1 ppm, 0-10 ppm, 0-50 ppm |
|
Germane (GeH ) |
0-2 ppm, 0-20 ppm |
|
Hydrazine (N H ) |
0-1 ppm, 0-300 ppm |
|
Tetrahydrothiophene (THT) |
0-100 mg/m³ |
|
Bromine (Br ) |
0-10 ppm, 0-100 ppm, 0-2000 ppm |
|
Acetylene (C H ) |
0-100% LEL, 0-100 ppm, 0-1000 ppm |
|
Ethylene (C H ) |
0-100% LEL, 0-100 ppm, 0-2000 ppm |
|
Ethanol (C H O) |
0-100 ppm, 0-2000 ppm, 0-100% LEL |
|
Methanol (CH O) |
0-100 ppm, 0-2000 ppm |
|
Carbon Disulfide (CS ) |
0-50 ppm, 0-5000 ppm |
|
Acrylonitrile (C H N) |
0-50 ppm, 0-2000 ppm |
|
Methylamine (CH N) |
0-50 ppm |
|
Iodine (I ) |
0-50 ppm |
|
Styrene (C H ) |
0-10 ppm, 0-100 ppm, 0-200 ppm, 0-1000 ppm, 0-5000 ppm |
|
Vinyl Chloride (C H Cl) |
0-100 ppm, 0-1000 ppm |
|
Trichloroethylene (C HCl ) |
0-100 ppm, 0-1000 ppm |
|
Tetrachloroethylene (C Cl ) |
0-100 ppm, 0-1000 ppm |
|
Nitrous Oxide (N O) |
0-100 ppm |
|
Nitrogen Trifluoride (NF ) |
0-100 ppm |
|
Hydrogen Peroxide (H O ) |
0-100 ppm, 0-1000 ppm |
|
Methyl Bromide (CH Br) |
0-100 ppm, 0-30000 ppm, 0-200 g/m³ |
|
Sulfuryl Fluoride (SO F ) |
0-100 ppm, 0-5000 ppm, 0-10000 ppm |
|
Benzene (C H ) |
0-10 ppm, 0-100 ppm, 0-1000 ppm, 0-10000 ppm |
|
Toluene (C H ) |
0-10 ppm, 0-100 ppm, 0-1000 ppm, 0-10000 ppm |
|
Xylene (C H ) |
0-10 ppm, 0-100 ppm, 0-1000 ppm, 0-10000 ppm |
|
VOC |
0-10 ppm, 0-100 ppm, 0-1000 ppm, 0-10000 ppm |
|
TVOC |
0-10 ppm, 0-100 ppm, 0-1000 ppm, 0-10000 ppm |
|
Non-Methane Total Hydrocarbons (CxHy) |
0-10 ppm, 0-100 ppm, 0-1000 ppm, 0-10000 ppm |
|
Refrigerants |
0-1000 ppm, 0-2000 ppm, 0-5000 ppm |
|
Sulfur Hexafluoride (SF ) |
0-1000 ppm, 0-2000 ppm, 0-3000 ppm |
