FEATURES 1. Hammering mechanism features air channel system （NEW） Powerful motors and optimized hammering to improve work efficiency. Large change lever （NEW） Rotation Only Rotation + Hammering Hammering Only Angle adjustment function (3-mode models only) Double-molded side handle （NEW） 360° rotation allows more effective operation. One-push action for quick bit mounting A bit can be mounted by simply inserting it into the tool holder.
Approximately 2 times longer life *1 achieved by reliable structure that includes a hammering mechanism same as our large hammers.
Up to 50% more volume of air cushion *1 reduces wear and damage inside cylinder.
2. Ball bearings （NEW）
Ball bearing seals in grease and holds temperature low to protect melt down of gear cover.
3. New internal pressure control mechanism （NEW）
Provides smooth airflow in or out of the gear cover to stabilize and ensure hammering action.
Located on the side of the tool body for easy operation!
For drilling in steel or wood, etc.
(with optional drill chuck and chuck adapter)
For drilling into concrete, etc.
(3-mode models only)
Chiseling of concrete or groove digging, etc.
When using a cold chisel or cutter, the orientation of the tool tip can be adjusted by setting the change lever as shown on the left.
Soft and easy to grip for comfortable operation!
Simple bit mounting
Specifications
Model
DH26PC2
DH26PB2
Capacity: Concrete
3.4 - 26mm (1/8" - 1")
Capacity: Steel
13mm (1/2")
Capacity: Core bit
25 - 50mm (1" - 2")
Capacity: Wood
32mm (1-1/4")
Power Input
830W
Bit Shank
SDS-plus
No-Load Speed
0 - 1,100min-1
Full-Load Impact Rate
0 - 4,300min-1
Overall Length
367mm (14-7/16")
Weight (excluding cord) *3
2.8kg (6.2lbs.)
Vibration Total Values
(triax vector sum) *4
Hammer drilling into concreteVibration emission value
ah, HD = 14.3m/s2
Uncertainty K = 1.5m/s2
Vibration Total Values
(triax vector sum)*4
Equivalent chiselling valueVibration emission value
ah, CHeq = 11.1m/s2
Uncertainty K = 1.5m/s2 —
Standard Accessories
Side Handle, Depth Gauge, Carrying Case
