Features
-3 modes of reaction time for automatic stop available both in forward and reverse rotation modes
-Trigger switch with full speed mode allows for less hand and finger fatigue
-Compact design with a short overall length of 170 mm (6-11/16")
-BL motor delivers 700 N·m (520 ft.lbs.) of max torque
-BL motor eliminates carbon brushes, enabling the BL motor to run cooler and more efficiently for longer life
-Ergonomically designed handle with soft grip provides increased comfort on the job
Specification
Square Drive 12.7 mm (1/2")
Fastening Capacities Standard Bolt:
M10 - M24 (3/8 - 1")
High Strength Bolt (Grade 10.9):
M10 - M16 (3/8 - 5/8")
High Strength Bolt (Grade F10T):
M12, M16 (7/16, 5/8")
Nut-Busting Torque 1,000 N·m (740 ft. lbs.)
Impacts Per Minute (IPM) Max: 0 - 2,700 | Hard: 0 - 2,400 | Mid: 0 - 1,700 | Soft: 0 - 1,000
Max Fastening Torque 700 N·m (520 ft. lbs.)
No Load Speed (RPM) Max: 0 - 2,200 | Hard: 0 - 1,900 | Mid: 0 - 1,200 | Soft: 0 - 500
Dimensions (L x W x H) 170 x 81 x 276 mm (6-11/16 x 3-3/16 x 10-7/8")
Net Weight 2.3 - 2.7 kg (5.1 - 6.0 lbs.)
Standard Equipment
Hook
Available Options
TJX1: 1x Rapid Charger, 2x 5.0Ah Battery, 1x Makpac Connector Box
ZX1: Without Charger, Battery & Carrying Case
