The powerful hammer with fastest drilling progress in its class:
• Fastest drilling progress – 30% faster than its predecessor
• High material removal rate – 50% more impact energy than existing GBH 5-38 D
• Perfect handling – well balanced tool for all applications
Functions & key features:
• Bosch Heavy Duty - Power, Performance and Robustness redefined!
• Construction - The professional power tools for construction from Bosch.
Specifications:
Additional data
Rated input power 1,100 W
Impact energy 8.5 J
Impact rate at rated speed 1,500 – 2,900 bpm
Rated speed 170 – 340 rpm
Weight 6.8 kg
Tool holder SDS max
Drilling range
Drilling dia. concrete, hammer drill bits 12 – 40 mm
Drilling dia. concrete, breakthrough drill bits 45 – 55 mm
Drilling diameter in concrete with core cutters 40 – 90 mm
Max. drilling diameter masonry, core cutters 90 mm
Max. drilling diameter concrete 40 mm
Opt. appl. range concrete, hammer drill bits 18 – 32 mm
Total vibration values (Hammer drilling in concrete)
Vibration emission value ah 14 m/s²
Uncertainty K 1.5 m/s²
Total vibration values (Chiselling)
Vibration emission value ah 11.5 m/s²
Uncertainty K 1.5 m/s²
Hammer drilling in concrete
Vibration emission value ah 14 m/s²
Uncertainty K 1.5 m/s²
Chiselling
Vibration emission value ah 11.5 m/s²
Uncertainty K 1.5 m/s²
