FEATURES
.png)
.png)
.png)
SPECIFICATIONS
| Engine | ||
| Type | : | 4-Stroke SOHC, liquid cooled |
| Bore X Stroke (mm) | : | 57.0 x 58.7 mm |
| Compression Ratio | : | 10.4:1 |
| Max Power | : | 11.3kW (8500rpm) |
| Max Torque | : | 13.8Nm(7000rpm) |
| Lubrication System | : | Wet Sump |
| Starter | : | Electric |
| Ignition | : | TCI |
| Chassis | ||
| Front Suspension | : | Telescopic |
| Rear Suspension | : | Swing arm |
| Front Brake | : |
Hydraulic Single Disc
|
| Rear Brake | : |
Hydraulic Single Disc
|
| Front Tyre | : | 70/90-17M/C (38P) |
| Rear Tyre | : | 120/70-17M/C (58P) |
| Overall Height (mm) | : | 1,100 |
| Wheelbase (mm) | : | 1,290 |
| Overall Length (mm) | : | 1,970 |
| Overall Width (mm) | : | 670 |
| Ground Clearance (mm) | : | 155 |
| Fuel Capacity (Liter) | : | 4.2 |
| Wet Weight | : | 115 kg |
