PUMA DNT2600LM DN Solutions Turning Center

PUMA DNT2600LM DN Solutions Turning Center

Category: Horizontal Puma Available
For more information, visit our official website at knbtech.com.my

Description

PUMA DNT Series

8''/10'' Global Standard Turning CenterIf you need for a heavy-duty standard turning center, the newly designed PUMA DNT machines with their high performance spindles and large work areas, give you a best-in-class, high-productivity turning solutions.



Redesigned Box-Guide Way

With a box guideway structure and impressive spindle power, the PUMA DNT brings stability to its impressive cutting capabilities



More Diversity & Outstanding Productivity

Variety of turret option -10st/12st/24st (position)
- High torque spindle option
- Various tailstock type
- Servo auto door for automation option




Improved User-Friendly Features

- No chip accumulation in the internal machine space
- Inverter type of chip conveyor
- User-friendly operation panel
- Steady rest installation that is easy to retrofit



SPECIFICATIONS

CAPACITY
Chuck size - 10 inch
Max.turning diameter - 380 mm
Max.turning length -
1030 mm

TRAVELS
X-axis rapid traverse - 24 m/min
Z-axis rapid traverse - 30 m/min
X-axis travel distance - 260 mm

Z-axis travel distance - 1100 mm

MAIN SPINDLE
Max.spindle speed - 3500 r/min
Max.spindle power - 26 kW
Max.spindle torque - 735 N.m

TURRET
No.of tool station - 12 ea

DIMENSIONS
Length - 3800 mm
Height - 1780 mm
Width - 1839 mm
Weight -
4950 kg
