| Manufacturer | EP |
|---|---|
| Model Designation | EFL 35 PRO |
| Drive | Electric |
| Operator Type | Seated |
| Load Capacity | 3500 kg |
| Load Center Distance | 500 mm |
| Load Distance, Centre of Drive Axle to Fork | 486 mm |
| Wheelbase | 1753 mm |
| Service Weight | 5250 kg |
| Axle Loading, Laden Front / Rear | 7748 / 1002 kg |
| Axle Loading, Unladen Front / Rear | 2267 / 2983 kg |
| Tyre Type | Pneumatic |
| Tyre Size, Front | 28x9-15-14PR |
| Tyre Size, Rear | 6.50-10-10PR |
| Wheels, Front / Rear | 2x / 2 |
| Tread Width, Front / Rear | 1010 / 980 mm |
| Tilt of Mast / Fork Carriage, Forward / Backward | 6 / 6 deg |
| Retracted Mast Height | 2065 mm |
| Free Lift | 135 mm |
| Lift Height | 3000 mm |
| Height, Mast Extended | 4130 mm |
| Height of Overhead Guard | 2170 mm |
| Seat Height | 1138 mm |
| Tow Coupling Height | 510 mm |
| Overall Length | 3682 mm |
| Length to Face of Forks | 2612 mm |
| Overall Width | 1210 mm |
| Fork Dimensions | 50 x 122 x 1070 mm |
| Fork Carriage Class / Type | 3A |
| Fork Carriage Width | 1100 mm |
| Ground Clearance, Below Mast | 130 mm |
| Ground Clearance, Centre of Wheelbase | 165 mm |
| Aisle Width, 1000 x 1200 Crossways | 4081 mm |
| Aisle Width, 800 x 1200 Lengthways | 4281 mm |
| Turning Radius | 2395 mm |
| Travel Speed, Laden / Unladen | 19 / 20 km/h |
| Lifting Speed, Laden / Unladen | 0.49 / 0.52 m/s |
| Lowering Speed, Laden / Unladen | 0.43 / 0.44 m/s |
| Max. Gradeability, Laden / Unladen | 20 / 28% |
| Service Brake | Hydraulic |
| Parking Brake | Electromagnetic |
| Drive Motor Rating | 17 kW |
| Lift Motor Rating | 30 kW |
| Battery Voltage / Nominal Capacity | 80V / 280Ah |
| Battery Weight | 184 kg |
| Drive Control | AC |
| Sound Pressure Level | <70 dB(A) |
| Source | EFL25,30,35 PRO (EN) Brochure_compressed.pdf |
