Diaphragm Pumps (AODD Pump)
HDF1 and HDF25 Metallic 1" (25 mm) AODD  Heavy Duty Flap Valve Pump
HDF1 and HDF25 Metallic 1" (25 mm) AODD  Heavy Duty Flap Valve Pump



HDF1 and HDF25 Metallic 1" (25 mm) AODD  Heavy Duty Flap Valve Pump

ABS Engineering & Trading Sdn Bhd flag
Kategori: Diaphragm Pumps (AODD Pump) Tersedia
Bisa dibeli di situs resmi
Untuk informasi lebih lanjut, kunjungi situs resmi kami di absfluidsolution.com
Kunjungi Situs Resmi Hubungi Kami
Specifications
  • Porting Size: 1" NPT 1" BSP
  • Capacity: 0 - 70 gpm (265 lpm)
  • Air Distribution Valve: No-lube, no-stall design
  • Heads up to: 125 psi or 289 ft. of water (8.6 bar or 88 meters)
  • Stroke: 0.10 gallons (0.38 liters)
  • Max Operating Pressure: 125 psi (8.6 bar)
  • Weight: Aluminum - 48 lbs (21 kg) Cast Iron - 76 lbs (34 kg) Stainless Steel - 79 lbs (36 kg)
Deskripsi

HDF1 and HDF25 Metallic AODD 1-inch Heavy Duty Flap Valve Pump, designed for robust fluid transfer in demanding industrial conditions.HDF1 and HDF25 Metallic 1" (25 mm) AODD – Heavy Duty Flap Valve Pump

The SANDPIPER HDF1 AND HDF25 METALLIC 1" (25 MM)  combine a small footprint with exceptional durability, designed specifically to handle abrasive slurries, solids-laden fluids, and harsh environments. Ideal for portable and permanent setups, this pump is perfect for sump, dewatering, and mining applications.





HDF1 and HDF25 Features



Applications
  • Superior Flow Rate: The HDF1 offers best-in-class flow for a 1” AODD pump, delivering efficient performance even in rugged applications.
  • Compact Design: With a small footprint, it easily fits into confined spaces, making it convenient for both portable and fixed applications
  • Bottom discharge Porting: Prevents settling solids from damaging the diaphragm, extending pump life.
  • Robust Construction: Built from sand-casted aluminum, cast iron, and stainless steel for maximum  durability in challenging environments
  • Air distribution System: Features a no-lube, no-stall ESADS+ system, allowing quick access for maintenance without removing the pump from service.

  • Sump and Dewatering:Excellent for moving solids-laden fluids and handling high-suction lift applications
  • MINING: Reliable Choice for harsh mining environments with superior abrasion resistance
  • Compact Installations: Fits confined spaces with its small, portable footprint.

Why Choose SANDPIPER AIR OPERATED DOUBLE DIAPHRAGM

Portability: Lightweight and easy to transport, ideal for multi-location use

Extended Pump Life: Bottom discharge porting reduces diaphragm wear from settling solids

Maintenance Efficiency: Externally serviceable ESADS+ system saves time, reducing downtime and operational costs.

HDF1 and HDF25 Metallic AODD 1-inch Heavy Duty Flap Valve Pump, designed for robust fluid transfer in demanding industrial conditions.



FOR MORE INFORMATION, CLICK HERE:
HDF1 and HDF25 Metallic 1" (25 mm) AODD – Heavy Duty Flap Valve Pump
