TL;DR: Texoil AW 46 is an HLP-type anti-wear mineral hydraulic fluid formulated to meet ISO VG 46 requirements for high-load stationary and mobile units. It delivers reliable wear protection, corrosion resistance, and demulsibility in continuous high-humidity, high-temperature Malaysian industrial environments.
ISO Viscosity Grade: ISO VG 46
Fluid Classification: Type HLP (demulsifying hydraulic fluid with anti-wear additives)
Base Stock: Selected refined mineral base oils
Density @ 15°C: 0.872 kg/m3 (0.872 g/cm3)
Kinematic Viscosity @ 40°C: 46.0 mm2/s (cSt)
Viscosity Index (VI): 98
Flash Point (COC): 210°C
Pour Point: -12°C
Filterability: High-grade fine filtration behavior
Hydraulic Vane, Piston, and Gear Pumps: Formulated to protect high-pressure pump components and motor elements against metal-to-metal wear.
Industrial Actuators & Control Valves: Applied in stationary manufacturing presses, plastic injection molding systems, and CNC machinery requiring consistent hydraulic force transmission.
Mobile Hydraulic Systems: Suitable for heavy construction, agricultural machinery, and materials handling equipment operating under continuous duty cycles.
Application Boundaries: Not intended for systems requiring zinc-free ashless fluids or fire-resistant hydraulic fluids (such as water-glycol HF-C or phosphate ester HF-D). Do not operate above the 210°C flash point threshold to prevent thermal oxidation breakdown.
Texoil AW 46 utilizes refined mineral base stock supplemented with polar anti-wear and anti-corrosion additive complexes. The chemical formulation maintains hydrolytic stability, preventing moisture-induced chemical degradation in humid ambient environments. Its demulsifying properties rapidly separate free water from the oil phase, allowing moisture to settle in reservoir sumps for easy drainage before emulsification can damage high-precision internal components.
Suitable For: Plant maintenance managers, OEM machinery engineers, and procurement teams seeking a reliable ISO VG 46 HLP fluid for industrial systems requiring ready stock availability in Selangor and the Klang Valley. Ideal for operations requiring standard 208L industrial drum supply or bulk top-up fluids for scheduled preventive maintenance.
Not Suitable For: High-temperature thermal fluid heat transfer networks, aviation hydraulic systems, food-processing equipment requiring NSF H1 registration, or applications operating in sub-zero freezer environments where a pour point lower than -12°C is required.
System Flushing: Drain old fluid entirely while warm. Flush sludged or heavily contaminated systems with a compatible low-viscosity flushing oil before charging.
Filter Replacement: Inspect reservoir sumps, remove accumulated sediment, and replace all system hydraulic suction and pressure line filters.
Fluid Charge: Introduce Texoil AW 46 directly into the hydraulic reservoir using dedicated transfer filtration units to prevent air ingress and external particulate entry.
Air De-aeration & Priming: Vent trapped air pockets at high point bleed valves and cycle actuators repeatedly under zero load to purge system air.
Operational Ramp-Up: Gradually elevate system pressure to normal operating levels while verifying oil levels, pump acoustics, and seals.
Water Contamination Ingress: Allowing excess water accumulation in the reservoir without regular draining degrades additive efficiency, despite strong hydrolytic stability.
Cross-Mixing Incompatible Oils: Intermixing with non-demulsifying oils or zinc-free fluids reduces filterability performance and alters wear protection metrics.
Overheating Above Limits: Operating sustained fluid temperatures near thermal thresholds accelerates oxidation, causing varnish and sludge build-up in hydraulic servo valves.
Used hydraulic oils are classified as Scheduled Waste under SW 305 or SW 306 pursuant to the Environmental Quality (Scheduled Wastes) Regulations 2005 in Malaysia. Waste oils must be contained in sealed, leak-proof drums, labeled clearly, and collected by licensed DOE contractors for recovery or off-site disposal. Avoid discharge into soil, storm drains, or watercourses.
Technical Data Sheets (TDS) and Safety Data Sheets (SDS) for Texoil AW 46 are available upon request for engineering audits, plant compliance reviews, and procurement validation.
What is the primary specification classification of Texoil AW 46?
Texoil AW 46 is a demulsifying, HLP-type anti-wear hydraulic oil meeting ISO VG 46 standards with a kinematic viscosity of 46.0 mm2/s at 40°C and a viscosity index of 98.
How does Texoil AW 46 handle moisture accumulation in tropical operating conditions?
The fluid features high demulsibility and hydrolytic stability, enabling fast separation of condensate water from the oil phase to preserve lubricity and protect pumps from corrosion.
Is Texoil AW 46 suitable for fine hydraulic filtration units?
Yes, Texoil AW 46 exhibits balanced filtration behavior, allowing passage through fine system
