| ELECTRICAL SPECIFICATION(STC) | |||||||||
| Maximum Power(Pmax/W) | 690 | 695 | 700 | 705 | 710 | 715 | 720 | 725 | 730 |
| Maximum Power Voltage(Vmp/W) | 42.82 | 43.02 | 43.21 | 43.40 | 43.59 | 43.78 | 43.96 | 44.14 | 44.32 |
| Maximum Power Current(Imp/A) | 16.14 | 16.18 | 16.23 | 16.27 | 16.30 | 16.33 | 16.39 | 16.43 | 16.48 |
| Open Circuit Voltage(Voc/V) | 49.04 | 49.10 | 49.17 | 49.29 | 49.30 | 49.37 | 49.44 | 49.51 | 49.58 |
| Short Circuit Current(Isc/A) | 17.14 | 17.22 | 17.31 | 17.39 | 17.47 | 17.55 | 17.62 | 17.70 | 17.78 |
| Module Efficiency(%) | 22.21 | 22.37 | 22.53 | 22.70 | 22.85 | 23.00 | 23.14 | 23.30 | 23.44 |
| Power Output Tolerance(%) | 0~+5% | ||||||||
| ELECTRICAL SPECIFICATION(NOCT) | |||||||||
| Maximum Power(Pmax/W) | 534 | 538 | 542 | 546 | 550 | 554 | 558 | 562 | 566 |
| Maximum Power Voltage(Vmp/W) | 38.54 | 38.73 | 38.91 | 39.10 | 39.29 | 39.49 | 39.67 | 39.86 | 40.05 |
| Maximum Power Current(Imp/A) | 13.86 | 13.90 | 13.93 | 13.96 | 14.00 | 14.03 | 14.07 | 14.10 | 14.13 |
| Open Circuit Voltage(Voc/V) | 45.68 | 45.75 | 45.82 | 45.89 | 45.96 | 46.03 | 46.10 | 46.17 | 46.24 |
| Short Circuit Current(Isc/A) | 14.63 | 14.43 | 14.50 | 14.57 | 14.63 | 14.70 | 14.77 | 14.84 | 14.91 |
| MECHANICAL DATA | |
| Number of Cells | 132 pieces(6x22) |
| Dimensions of Module L*W*H(mm) | 2384x1303x35mm |
| Weight(kg) | Approx 38.7kg |
| Front Side Glass | 2.0mm, Anti-reflection coating glass |
| Back Side Glass | 2.0mm HeatStrengthened Glass |
| Frame | Anodized Aluminium |
| J-Box | IP68 Rated |
| Cable | 4.0mm², +300mm |
| Number of diodes | 3 |
| Wind/Snow Load | 2400 Pa/5400pa* |
| Connector | MC4 compatible or MC compatible |
