| ELECTEICAL SPECIFICATION(STEC) | |||||
| Maximum Power(Pmax/W) | 540 | 545 | 550 | 555 | 560 |
| Maximum Power Voltage(Vmp/V) | 41.45 | 41.70 | 41.93 | 42.18 | 42.13 |
| Maximum Power Current(Imp/A) | 13.03 | 13.07 | 13.12 | 13.16 | 13.20 |
| Open Circuit Voltage(Voc/V) | 49.24 | 49.52 | 49.80 | 50.08 | 50.36 |
| Short Circuit Current(Isc/A) | 13.78 | 13.83 | 13.88 | 13.93 | 13.98 |
| Module Efficiency(%) | 20.9 | 21.1 | 21.3 | 21.5 | 21.7 |
| Power Output Tolerance(W) | 0~+5% | ||||
| ELECTRICAL SPECIFICATION(NOCT) | |||||
| Maximum Powert(Pmax/W) | 408.6 | 412.4 | 416.2 | 420.0 | 424.1 |
| Maximum Power Voltage(Vmp/W) | 38.45 | 38.67 | 38.90 | 39.12 | 39.34 |
| Maximum Power Current(Imp/A) | 10.62 | 10.66 | 10.70 | 10.74 | 10.78 |
| Open Circuit Voltage(Voc/V) | 46.48 | 46.74 | 47.01 | 47.28 | 47.55 |
| Short Circuit Current(Isc/A) | 11.04 | 11.08 | 11.12 | 11.16 | 11.20 |
| MECHANICAL DATA | |
| Number of Cells | 144 pieces(6x24) |
| Dimensions of Module L*W*H(mm) | 2278x1134x30/35mm |
| Weight(kg) | Approx 32.0/32.3kg |
| Front Side Glass | 2.0mm, Anti-reflection coating glass |
| Back Side Glass | 2.0mm, Heat Strengthened glass |
| Frame | Anodized Aluminium |
| J-Box | IP68 Rated |
| Cable | 4.0mm², +300mm |
| Number of diodes | 3 |
| Wind/Snow Load | 2400Pa/5400Pa * |
| Connector | MC4 compatible or MC compatible |
